GAZ COILOVER SUSPENSION KIT, FORD SIERRA/SAPPHIRE COSWORTH 2WD , RS500 & 2WD BASE MODELS GZGHA326G

Gaz Height Adjustable kits are primarily made for the modified road car market. The main features of these kits are:

• On car damping adjustment by use of a 36 point external adjuster.
• Shortened body and stroke lengths to allow a -25 to -65mm ride height adjustment.
• The units have a coarse acme form thread for ease of adjustment and to minimise corrosion the unit is zinc plated.
• All units are provided with high quality 2.25" coil springs along with polyurethane bump stops. Spring rates can be altered on request to suit customer's requirements.
• Each unit is fully rebuildable and they are supplied with a 2 year warranty and an individual dyno read out.

N.B.These kits can obtain much lower ride heights for show purposes only but the vehicle should not be driven at these levels as the steering and drive shafts joints can lock out.

Application:

• Ford Sierra RS Cosworth 3 door 1986-1987
• Ford Sierra Cosworth RS500 1987
• Ford Sierra Sapphire RS Cosworth 2wd 1988-1989

The following base models will require the upper rear damper bolt modifying from M10 to M12 (Cosworth spec). This means the mounting location in the chassis must be drilled from 10mm to 12mm. You must also source two M12x65 bolts with nuts as they are not supplied in this kit. Rear dampers do not fit estate models.

• Ford Sierra 1.3/1.6/1.8/2.0/2.3/2.3D 2wd (not estate) 1982-1992
• Ford Sierra XR4i 1984-1985

Note: Gaz recommend the fitment of a rear strut brace when fitting their coilover kits for additional strength and support.
